Count
The total machining times of the program file.
When cycle machining is disabled, the single total time is equal to total time,
and single total length is equal to total length.
See Execute Cycle Machining for cycle machining.
In Part Statistic interface, you can also do the following:
• To clear all statistics, press F1.
• To export all statistics to a USB flash disk, press F2.
The statistics will be saved as a TXT file.
5.7 Compensate the Tool
This operation is used to compute the corresponding coordinates of the tool center
or the related point of the tool rest, according to the actual coordinate position of
the tool rest or the cutting edge.
With this operation, you can directly input the new tool parameter values in the
Compensation interface, if the tool nose radius is altered due to tool wear, tool
sharpening or tool change. It saves trouble of modifying the programmed program
file.
Before compensating the tool, do the following:
• Set parameter Enable Cutter Compensation to Yes to enable tool
compensation.
• Set parameter Tool Compensation Type based on your own needs.
• Measure and record the following values:
– Tool diameter
– Tool diameter wear
– Tool length
– Tool length wear
