2. Optional: To select the target WCS, do the following:
1. Press ← / →, and move the cursor to the coordinate column.
Its color turns into light blue.
2. Press F1 to select the coordinate system.
The WCS name shows in the WCS column of the coordinate display area.
3. To set the workpiece offset, do the following:
1. Press ↑ / ↓ / ← / →, and select the target input box.
2. Press Enter, and input the workpiece offset.
4. To set the public offset, do the following:
1. Press ↑ / ↓ / ← / →, and select the target input box.
2. Press Enter, and input the workpiece offset.
3. To adjust Z-axis public offset, press F5, set adjusted distance, and press
F6 / F7 to deepen (reduce) / lift (increase) the public offset.
3.5 Execute Machining
This operation is used to run the program from the beginning to the end.
To execute machining, do the following:
1. To enter into AUTO mode, press .
2. To start machining, press .
The system automatically switches to Coor-Auto interface and executes the
program file until the end of block or any intentional interruption.
During machining, you can do one of the following to control machining:
• To stop machining in advance, press .
• To resume machining from the exact interrupted position when power
interruption or E-stop occurs and the workpiece origin is secured, press .
