3. Optional: To rename the program task, press F3.
4. To open the program task for later editing, press F6.
5. To enter into File List page, press F7 → F1.
6. Optional: To add program files in the USB flash disk into the program task,
press F6.
It is default to add local program files.
7. Press ↑ / ↓ and F2 / F3 / F4 to select the target file, and press F1 to add it into
the program task.
Press F7 to exit creating the program task.
4.5.2 Edit the Program Task
To edit the program task, do the following:
1. Press ↑ / ↓ / ← / → to select the target input box, press Enter and modify the
following:
– Used WCS
– Machining interval
– Machining times
2. Press F3, press ↑ / ↓, and do one of the following:
– To modify the machining order in the program task, press F1 / F2.
– To remove the target program file from the program task, F3.
3. To save the modification, press F6.
4.5.3 Start the Program Task
To execute the program task, do the following:
1. To select a machining mode, do the following:
– To select One by One Mode, press N.
– To select Single Mode, press T.
2. Optional: To set cycle times for the program task, press S.
3. To load the program task, press F6. Names of the program task and the first
program file in the task show above the display screen.
4. Optional: To set the first program file, press L.
