上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD
43 / 52
2. To save coordinates, do the following:
1. Press ↑ / ↓ to select the target line No.
2. Press F1. The system saves the workpiece offsets of the current program
file into the target line No.
If the workpiece offset already exists in the target line No., the operation will
overwrite it.
3. To recover coordinates, do the following:
1. To select the target line No, press ↑ / ↓.
2. Press F2, and choose whether to recover the workpiece offset of Z-axis:
• To recover the workpiece offsets of all axes, press Y in the two
pop-up dialog boxes.
• To recover the workpiece offsets except Z-axis, press Y only in
the first pop-up dialog box.
