4 Assembly
2. Close the hook and loop fasteners on the tension belts.
Result The tension belts are attached to the portable unit.
4.4 Attaching the oxygen cylinder to
the portable unit
4.4.1 Attaching the oxygen cylinder Ø 105 mm
Applies to • LIFE-BASE Mini II
• LIFE-BASE III
• LIFE-BASE 3 NG
• LIFE-BASE 4 NG
Damage to cylinder brackets!
The tensioning force of the cylinder brackets can be set differently.
If the cylinder brackets can only be closed by applying significant
force, the brackets may be overstretched and damaged.
Choose the tensioning force so that the oxygen cylinder
is fastened securely, yet the cylinder brackets can still be
closed with a normal amount of force and without auxiliary
equipment.
Adjust the cylinder brackets precisely to the diameter of
the oxygen cylinder with the fine adjustment system.
