Weinmann LIFE-BASE Series User Manual

WM 68331 04/2021
LIFE-BASE EN 121
7 Disassembly
2. Remove the tension belts from the portable unit.
Result The tension belts are removed from the portable unit.
7.4 Removing the oxygen cylinder from
the portable unit
7.4.1 Disassembling the oxygen cylinder Ø 105 mm
Applies to • LIFE-BASE Mini II
• LIFE-BASE III
• LIFE-BASE 3 NG
• LIFE-BASE 4 NG
1. Open the latches (1) on the cylinder brackets.
2. Unhook the tensioning hoop (2) from the lock-in position on
the cylinder brackets.
1
2
