4 Assembly
12. Complete attachment of the device to the portable unit
(see "4.5.7 Completing assembly", page 80).
Result The device is attached to the portable unit.
Attaching the ventilator and MEDUCORE Standard
2
Applies to • MEDUMAT Standard
2
• MEDUVENT Standard
• MEDUMAT Easy
CPR
• MEDUCORE Standard
2
Required auxiliary
equipment
Screwdriver with crosshead PH1
1. If available: Fasten the shoulder strap to the portable unit
(see "4.3 Attaching the belt to the portable unit", page 36).
2. With MEDUMAT Standard
2
and MEDUMAT Easy
CPR
:
Connect the low-pressure hose to the compressed gas
connection on the side or on the rear of the ventilator.
3. Place devices with the control panel membrane facing down.
