WM 68331 04/2021
LIFE-BASE EN 59
4 Assembly
Attaching the monitor/defibrillator
Applies to • MEDUCORE Standard
2
• MEDUCORE Standard
Required auxiliary
equipment
Screwdriver with crosshead PH1
1. If available: Fasten the shoulder strap to the portable unit
(see "4.3 Attaching the belt to the portable unit", page 36).
2. Position the device with the control panel membrane facing
downwards.
3. Determine the holes for the device on the spacer plate.
4. Place the spacer plate on the device.
When doing so, note:
• Every device has a certain position.
MEDUCORE Standard
MEDUCORE Standard
2
MEDUCORE Standard
on LIFE-BASE 3 NG
On LIFE-BASE 1 NG XL
