7 Description of the modes
7.4.5 Inhalation mode
The Inhalation mode is used for the application of a defined
oxygen flow of 1-10 l/min via a corresponding interface.
To connect the interface, an inhalation adapter is required,
which is attached to the connection for the ventilation hose on
the device. On delivery, the inhalation adapter is secured to the
connection for the ventilation hose by a retaining band.
7.4.6 CO
2
monitoring mode
Description
Abbreviation -
Long form Inhalation
Type -
Requirement Inhalation option is activated
Ventilation parameters
Left-hand navigation knob -
Central navigation knob -
Right-hand navigation knob Inhalation flow
Description
Abbreviation -
Long form CO
2
monitoring
Type -
Requirement Capnography option is activated
Ventilation parameters
Left-hand navigation knob -
Central navigation knob -
Right-hand navigation knob -
