WM 68071 05/2021
MEDUMAT Standard
2
EN 231
14 Appendix
14 Appendix
14.1 Technical data
14.1.1 Technical data on device
Specification Device
Product class according to
Directive 93/42/EEC
IIb
Dimensions (W x H x D) 206 mm x 138 mm x 130 mm
Weight:
Without battery
With battery
Approx. 2 kg
Approx. 2.5 kg
Weight with Capnography option:
Without battery
With battery
Approx. 2.15 kg
Approx. 2.65 kg
Operation:
Temperature range
Humidity
Air pressure
Height above sea level
-20 °C to +50 °C
0 % RH to 95 % RH without condensation
540 hPa to 1100 hPa
-500 m to 5000 m
Storage (device)/transport:
Temperature range
Humidity
Air pressure
Height above sea level
-40 °C to +70 °C
0 % RH to 95 % RH without condensation
540 hPa to 1100 hPa
-500 m to 5000 m
Electrical connection (rated voltage) 12 V
Permitted operating voltage 10.2 V to 15.1 V
Max. power consumption 30 W
Disconnection from line power
Pulling out the power plug disconnects the device from
line power on all poles.
Current consumption 0.1 to 3 A
Input voltage
(external power supply unit)
100 V-240 V~/50 Hz-60 Hz
Operating time with battery
without CO
2
measurement
with activated CO
2
measurement
Approx. 10 h
Approx. 9 h
The specified battery runtime applies under the following
conditions: Ambient temperature = 21 °C, ventilation: Emergency
Adult, new battery
