24 EN MEDUMAT Standard
2
WM 68071 05/2021
3 Description
5 Filter compartment Houses the hygiene filter.
6 Battery compartment with battery Houses the battery.
7 Power supply connection Connects the device to the power supply.
8 Compressed gas connection
Used for connecting the oxygen supply
(e.g., an oxygen cylinder).
9 SD card slot For inserting an SD card.
10 Loudspeaker Emits audible alarms and metronome sounds.
11 Security seal
Indicates whether the device has been opened
without authorization.
12 Connection for measuring circuit
Connects the device to the measuring circuit of the
breathing circuit.
13 Connection for ventilation hose
Connects the device to the ventilation hose of the
breathing circuit.
14 Connection for CO
2
measuring tube
Connects the device to the CO
2
measuring tube
(only with Capnography option). This connection
is included with devices without the Capnography
option; however, it has no function.
15 Connection for pressure measuring tube Connects the device to the pressure measuring tube.
16 Connection for PEEP control tube Connects the device to the PEEP control tube.
No. Designation Description
