MEDUMAT Standard
2
EN 29
3 Description
No. Designation Description
1 Pressure gauge
• Indicates ventilation pressure progress.
• Indicates pMax
as a dotted line.
• Indicates the currently attuning airway pressure
as a green area.
• Indicates the maximum airway pressure in the
middle.
• Indicates the end-tidal CO
2
concentration (etCO
2
)
in the middle (only with Capnography option).
2
End-tidal CO
2
concentration (etCO
2
)
(only with Capnography option)
Indicates the end-tidal CO
2
concentration.
If the Capnography option is deactivated,
the peak pressure is shown here (pPeak).
3 Time Displays the current time.
4
100 % O
2
Air Mix
Indicates whether operation with 100 % oxygen
or Air Mix mode is activated.
5 Ventilation mode indicator Indicates the currently selected ventilation mode.
6 Inspiration time (Ti)
Indicates the inspiration time.
If an alarm is displayed, this information is omitted.
7 Peak pressure (pPeak) Indicates the maximum pressure.
8 Plateau pressure (pPlat) Indicates the pressure during the plateau time.
9 Mean pressure (pMean) Indicates the mean pressure over all measurements.
10 Blue arrow
Provides access to the application menu
(turn or press the right-hand navigation knob).
11
Pressure curve (only with Flow
measurement + ASB option and Curve
display option or Capnography option)
Indicates the pressure progress.
12
Flow curve (only with Flow
measurement + ASB option)
Indicates the flow progress.
13
Leakage (Vleak) (only with Flow
measurement + ASB option)
Indicates leaks.
14 Positive end-expiratory pressure (PEEP)
• Indicates the positive end-expiratory pressure.
• Enables the positive end-expiratory pressure to
be set.
15 Frequency (Freq.)
• Indicates the ventilation rate.
• Enables the ventilation rate to be set.
16 Tidal volume (Vt)
• Indicates the tidal volume.
• Enables the tidal volume to be set.
17
Expiratory minute volume (MVe) (only
with Flow measurement + ASB option)
Indicates the expiratory minute volume and
the associated alarm limits.
