36 EN MEDUMAT Standard
2
WM 68071 05/2021
3 Description
No. Designation Description
1
Service label (only with reusable
breathing circuit)
Indicates the date when the next maintenance is due.
2
Protective sleeve (only with reusable
breathing circuit)
Protects the ventilation hose against dirt and damage.
3 Hook and loop strap with clip
• Fixes the breathing circuit to the patient's
clothing.
• Fixes MEDUtrigger to the breathing circuit when
not in use (e.g., during CPAP applications).
4
Protective cap (only with reusable
breathing circuit)
Protects the end of the breathing circuit closest to
the patient from damage.
5
Connector with CO
2
connection
(only with reusable breathing circuit,
only with Capnography option)
Enables connection of the CO
2
measuring tube to
the breathing circuit.
6 Elbow
Connects the rest of the breathing circuit to the mask
or endotracheal tube.
7
FlowCheck sensor connector (only with
Flow measurement + ASB option)
Connects one of the following connection lines to
the FlowCheck sensor:
• FlowCheck sensor connection line
• FlowCheck sensor connection line with
MEDUtrigger
8
FlowCheck sensor (only with Flow
measurement + ASB option)
Measures the flow to the patient and to the device.
9 Patient valve Switches between inspiration and expiration.
10
CO
2
measuring tube (only with
Capnography option)
Conducts patient's respiratory gas to CO
2
measurement in the device.
11 PEEP control tube
The device controls the patient valve and the PEEP
via the PEEP control tube.
12 Pressure measuring tube Measures the ventilation pressure at the patient.
13
Hose clip (only with disposable
breathing circuit)
Keeps the hoses/tubes and the connection line
together.
14 Ventilation hose
The respiratory gas flows from the device to the
patient valve through the ventilation hose.
15
FlowCheck sensor connection line
with MEDUtrigger (only with Flow
measurement + ASB option)
Connects MEDUtrigger and the FlowCheck sensor to
the device. Alternatively, you can also connect the
FlowCheck sensor connection line or the connection
line of MEDUtrigger here.
