3 Description
Battery status
Battery clicks audibly into place
Indicates the correct installation direction of the PEEP control diaphragm.
Date stamp for year and month
Indicates the date when the next maintenance is due
(position: on the service label).
Indicates the correct flow direction during inspiration.
>PP< Material designation: Polypropylene
>PC< Material designation: Polycarbonate
134 °C Steam sterilization at 134 °C
Symbol Description
