1.
Legend
1.
Handle for lifting or moving
2.
On/Off knob
3.
Warning notices
4.
Operating hours meter
5.
Oxygen outlet
6.
Connecting nipple with union nut (fitted)
7.
Connecting tube (20 m)
8.
Castors with brake
9.
Dosage monitor
10.
Power cord
11.
Connecting tube (3 m) for nasal cannula
12.
Nasal cannula
13.
Coarse dust filter
14.
Power cord socket
15.
Fuse holder
16.
Flowmeter
17.
Connecting tube (10 m)
18.
Fault indicator (red)
19.
Oxygen concentration status indicator (yellow)
20.
Power indicator (green)
21.
Dosage unit (flowmeter)
22.
Ball, indicates flow
23.
Connection, long tube to
OXYMAT
3
(20 m)
24.
Flow control knob
25.
Humidifier glass of bubble humidifier
26.
Connection, 3 m hose to nasal cannula
27.
Flow control knob
28.
Connection,
OXYMAT
3
29.
Connection for tubes (3
m or 10
m)
