4.3 Connecting to flowmeter
and nasal cannula
1. Screw connection 28 of flowmeter 16 to
oxygen outlet 5 of the OXYMAT 3.
2. Now attach the 10-meter connecting
hose 17 to nasal cannula 12 and to
connection 28 on the flowmeter.
3. Now you can use the power cord to con-
nect the OXYMAT 3 to a power outlet.
Note that it needs a mains voltage of
230 V.
