94
English
• Yellow status indicator 19 of the O
2
con-
centrator; only comes on if a fault is de-
tected during the self-test which might
lead to reduced performance of the de-
vice. In this case, contact your author-
ized dealer.
• Red fault indicator 18; this lamp comes
on in the event of either a power failure
or the device failing. You will simultane-
ously hear an intermittent alarm (see "8.
Troubleshooting" page 110).
Indicator on dosage unit
You can read off the flow rate at the top of
ball 22 in the dosage unit. The flow is indicat-
ed in liters per minute.
Indicator on flowmeter
You can read off the flow rate at the top of
ball 22 on the flowmeter 16. The flow rate is
indicated in liters per minute.
5.4 Storing OXYMAT 3
If you will not be using the device for some
time, be sure to clean and dry the humidifier,
tube system and nasal cannula before storing
them.
