Item Protective device Function Check
7
(installed by
customer)
Disconnector
■
Installed by the customer close to
the appliance; easily visible and
accessible, 3-pole action, mini-
mum contact separation 3
mm.
■
Used to disconnect the appliance
from the power supply during
cleaning, repair and servicing
work and in a hazardous situation
Action:
■
T
rip the disconnector
■
Check at the -X10 terminal strip on
the appliance that none of the
three phases carry a live voltage
8
(installed by
customer)
Gas shut-off device
■
Installed by customer close to ap-
pliance in easily accessible posi-
tion and clearly labeled
■
Used to disconnect the appliance
from the gas supply during clean-
ing, repair and servicing work and
in a hazardous situation
Action:
■
Close gas shut-off device
■
Check that the appliance is isola-
ted from the gas supply
Safety measures
The following measures increase the safety additionally:
Measure Function Check
Magnetic switch for appli-
ance door (electric door sen-
sor)
■
When the appliance door is opened, the
switch stops:
■
rotation of the fan wheel (comes to a
stop after a few seconds)
■
operation of the heating element
■
Distribution of the cleaning products by
the fully automatic oven cleaning sys-
tem
■
Prompt to close the appliance door
Check magnetic door switch at low tempera-
ture
Action:
■
Open the appliance door fully
■
Press Start
Result:
Motor must not start up.
Restart after power failure in
case cleaning agent was left
in the appliance
■
Restarts fully automatic oven cleaning in a
defined state after power failure
None
