Welbilt Convotherm 4 Installation Manual

9.3 Electrical supply, EB/ES
C4 EB (three-phase FC)
12.20 20.10 20.20
3~ 400V 50/60Hz
Rated power consumption [kW] 33.7 38.9 67.3
Convection power [kW] 33.3 38.1 66.5
Steam power [kW] 31.6 31.6 40.2
Motor power [kW] 0.35 0.7 0.7
Rated current [A] 48.7 56.2 97.3
Fuse rating [A] 50 63 100
Residual current [mA] - - -
Protective earth current [mA] - - -
Recommended conductor cross-section for wires laid uncovered in air up to 5 m in
length.
[mm
2
]
5G16 5G16 5G35
Residual-current device Type B B B
C4 ES (three-phase FC)
12.20 20.10 20.20
3~ 400V 50/60Hz
Rated power consumption [kW] 33.7 38.9 67.3
Convection power [kW] 33.3 38.1 66.5
Motor power [kW] 0.35 0.7 0.7
Rated current [A] 48.7 56.2 97.3
Fuse rating [A] 50 63 100
Residual current [mA] - - -
Protective earth current [mA] - - -
Recommended conductor cross-section for wires laid uncovered in air up to 5 m in
length.
[mm
2
]
5G16 5G16 5G35
Residual-current device Type B B B
C4 EB (single-phase FC)
12.20 20.10 20.20
3N~ 400V 50/60Hz (3/N/PE)
Rated power consumption [kW] 33.7 38.9 67.3
Convection power [kW] 33.3 38.1 66.5
Steam power [kW] 31.6 31.6 40.2
Motor power [kW] 0.35 0.7 0.7
Rated current [A] 48.7 56.2 97.3
Fuse rating [A] 50 63 100
Residual current [mA] ~7.5 ~16.5 ~16.5
Protective earth current [mA] ~7.5 ~16.5 ~16.5
Recommended conductor cross-section for wires laid uncovered in air up to 5 m in
length.
[mm
2
]
5G16 5G16 5G35
Residual-current device Type A/B A/B A/B
