9.8 Electrical supply, marine
C4 EB (three-phase FC)
12.20 20.10 20.20
3~ 440V 50/60Hz
Rated power consumption [kW] 28.2 32.6 56.3
Convection power [kW] 27.8 31.8 55.5
Steam power [kW] 26.3 26.3 33.6
Motor power [kW] 0.35 0.7 0.7
Rated current [A] 37.0 42.8 73.9
Fuse rating [A] 50 50 100
Residual current [mA] - - -
Protective earth current [mA] - - -
Recommended conductor cross-section for wires laid uncovered in air up to 5 m in
length.
[mm
2
]
4G16 4G16 4G35
Residual-current device Type B B B
3~ 480V 50/60Hz
Rated power consumption [kW] 33.4 38.6 66.8
Convection power [kW] 33.0 37.8 66.1
Steam power [kW] 31.3 31.3 39.9
Motor power [kW] 0.35 0.7 0.7
Rated current [A] 40.3 46.5 80.5
Fuse rating [A] 50 50 100
Residual current [mA] - - -
Protective earth current [mA] - - -
Recommended conductor cross-section for wires laid uncovered in air up to 5 m in
length.
[mm
2
]
4G16 4G16 4G35
Residual-current device Type B B B
C4 ES (three-phase FC)
12.20 20.10 20.20
3~ 440V 50/60Hz
Rated power consumption [kW] 28.2 32.6 56.3
Convection power [kW] 27.8 31.8 55.5
Motor power [kW] 0.35 0.7 0.7
Rated current [A] 37.0 42.8 73.9
Fuse rating [A] 50 50 100
Residual current [mA] - - -
Protective earth current [mA] - - -
Recommended conductor cross-section for wires laid uncovered in air up to 5 m in
length.
[mm
2
]
4G16 4G16 4G35
Residual-current device Type B B B
3~ 480V 50/60Hz
Rated power consumption [kW] 33.4 38.6 66.8
Convection power [kW] 33.0 37.8 66.1
Motor power [kW] 0.35 0.7 0.7
