Welbilt Convotherm 4 - Dissipated Heat; Water Connection

9.21 Dissipated heat
C4 EB/ES
10.10 20.10 20.20
With appliance door closed
Latent heat [kJ/h]
[kW]
6900
1.92
6900
1.92
11000
3.06
Sensible heat [kJ/h]
[kW]
7800
2.17
8900
2.47
14100
3.92
C4 GB/GS
12.20 20.10 20.20
With appliance door closed
Latent heat [kJ/h]
[kW]
8200
2.28
7100
1.97
12200
3.39
Sensible heat [kJ/h]
[kW]
11000
3.06
11000
3.06
15400
4.28
9.22 Water connection
C4 EB/ES/GB/GS
Water supply (cold only)
Shut-off device With EA (verifiable) check valve and dirt filter
Water supply 2 x G 3/4'' fixed connection, optionally including
connecting pipe (min. DN13 / 1/2'')
Flow pressure [kPa] 150 - 600 (1.5 - 6 bar)
Pressure gauge in the water supply [kPa] 150 (1.5 bar)
Water drain
Model Fixed connection (recommended) or open tank
or channel/gully
Type DN 50
Waste water temperature [°C] max. 80
Slope for drain pipe min. 3.5% (2°)
Safety overflow [mm] 80 x 25 mm
C4 EB/ES/GB/GS (for United Kingdom)
Water supply (cold only)
Shut-off device With double check valve (type BA or CA) and
dirt filter
Water supply 2 x G 3/4'' fixed connection, optionally including
connecting pipe (min. DN13 / 1/2'')
Flow pressure [kPa] 150 - 600 (1.5 - 6 bar)
Pressure gauge in the water supply [kPa] 150 (1.5 bar)
Water drain
Model Fixed connection (recommended) or open tank
or channel/gully
Type DN 50
9 Technical data
Installation manual 95
