4 Transportation
4.1
Conveying the appliance to the installation location
Space required for conveying the appliance
Make sure that there is enough width and height along the entire route used for conveying the appliance to ensure it can get
through to its installation location.
The table below shows the dimensions of the appliances including packaging, which are needed to determine the minimum
doorway dimensions required to allow the appliance to be brought to its installation location:
12.20 20.10 20.20
Width
[mm] 1410 1165 1410
Height
[mm] 1615 2150 2150
Depth
[mm] 1170 970 1170
Load bearing capability for conveying the appliance
Provide moving equipment that is rated capable of carrying the load.
Refer to the weight of the appliance including packaging to determine the minimum working load limit of handling equipment;
see 'Dimensions and weights
'Technical data' on page 74.
Conveying the appliance to the installation location for the first time
Please observe the following points when conveying the appliance:
■
Always move the appliance on a pallet.
■
Always move the appliance in an upright position.
■
Use a forklift truck or pallet truck to lift the appliance.
■
Move the appliance slowly and carefully
, and secure it against tipping over.
Make sure that you do not knock against things with the appliance.
Avoid moving appliance along uneven routes or up or down steep slopes.
4.2 Preparing to unpack
Preparing to unpack
Perform the following tasks before unpacking the appliance:
■
Check the outer packaging for damage.
■
T
ake the unpacking instruction leaflet out of the shipping documents.
