Frequency converter (single phase) Frequency converter (three phase)
Rated voltage
3~ 220 V 60 Hz 3~ 480 V 60 Hz
3~ 230 V 50/60 Hz -
3~ 200 V 50/60 Hz -
1N~ 230V 50/60 Hz -
1N~ 220V 60 Hz -
1N~ 100V 50/60 Hz -
1N~ 120V 60 Hz -
2~ 230 V 50/60 Hz -
Recommended residual-current device (RCD)
Type A/B Type B
Properties of the residual-current device
The residual-current device (RCD) must have the following properties:
■
Filter for filtering out RF currents
■
"T
ime delayed" trip characteristic for RCD devices with trip threshold £30 mA:
prevents RCD being tripped by charging currents of capacitors and parasitic capacitances when appliance is switched
on.
■
"Leakage current protection, type SI" trip characteristic for RCD devices with trip threshold £30 mA:
insensitive to nuisance tripping.
Mains supply connection
The power cord must be an oil-resistant, sheathed and flexible cable in accordance with IEC 60245 (e.g. H05RN-F, H07RN-
F). A maximum cable length of 5
m is recommended.
The appliance does not need to be connected in a specific phase sequence or a specific direction of rotation.
6 Installation
Installation manual 41
