4.
Plug the red extractor tube (4) for the ConvoClean forte or
ConvoClean new cleaning agent onto the connector nipple of the front
tube fitting (G) and secure the tube in place with the wire clip (3) (see
label for cleaning-agent connection on the left-hand side of the appli-
ance).
5.
Insert the suction nozzle on the red extractor tube (4) into the clean-
ing-agent canister (5). There must be no kinks in the tube and the vent
hole in the canister must be open and unblocked.
