Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 143
10 OR Alarm Event Reverse
11 AND Alarm Event Direct
12 AND Alarm Event Reverse
Output 3B Function Value Output 3B Function
Dec 10104 26488 52976
RW
0 Disabled
Hex 2778 6778 CEF0
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Loop 1 VMD Open
4 Loop 1 VMD Close
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Loop 2 VMD Open
8 Loop 2 VMD Close
9 OR Alarm Event Direct
10 OR Alarm Event Reverse
11 AND Alarm Event Direct
12 AND Alarm Event Reverse
Output 3 OR Alarm Selection Bit If Bit = 1, Alarm n Is Included in OR Selection
Dec 10119 26503 53006
RW
2 Alarm 1
Hex 2787 6787 CF0E
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 3 OR Event Selection Bit If Bit = 1, Event n Is Included in OR Selection
Dec 10120 26504 53008
RW
2 Event 1
Hex 2788 6788 CF10
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 3 AND Alarm Selection Bit If Bit = 1, Alarm n Is Included in AND Selection
Dec 10121 26505 53010
RW
2 Alarm 1
Hex 2789 6789 CF12
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 3 AND Event Selection Bit If Bit = 1, Event n Is Included in AND Selection
Dec 10122 26506 53012
RW
2 Event 1
Hex 278A 678A CF14
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
