Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 144
Output 3B OR Alarm Selection Bit If Bit = 1, Alarm n Is Included in OR Selection
Dec 10123 26507 53014
RW
2 Alarm 1
Hex 278B 678B CF16
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 3B OR Event Selection Bit If Bit = 1, Event n Is Included in OR Selection
Dec 10124 26508 53016
RW
2 Event 1
Hex 278C 678C CF18
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 3B AND Alarm Selection Bit If Bit = 1, Alarm n Is Included in AND Selection
Dec 10125 26509 53018
RW
2 Alarm 1
Hex 278D 678D CF1A
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 3B AND Event Selection Bit If Bit = 1, Event n Is Included in AND Selection
Dec 10126 26510 53020
RW
2 Event 1
Hex 278E 678E CF1C
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 4 Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Linear Output 4 Fitted Value Linear Output 4 Fitted
Dec 3000 19384 38768
RO
0 Not fitted
Hex 0BB8 4BB8 9770
1 Fitted
Output 4 Usage Value Output 4 Function
Dec 10105 26489 52978
RW
0 Disabled
Hex 2779 6779 CEF2
1 Loop 1 Primary Output Power
2 Loop 1 Secondary Output Power
3 Loop 1 VMD Open
4 Loop 1 VMD Close
5 Loop 2 Primary Output Power
6 Loop 2 Secondary Output Power
7 Loop 2 VMD Open
