Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 145
8 Loop 2 VMD Close
9 OR Alarm Event Direct
10 OR Alarm Event Reverse
11 AND Alarm Event Direct
12 AND Alarm Event Reverse
Output 4 Status Value Output 4 Status
Dec 3001 19385 38770
RO
0 Inactive
Hex 0BB9 4BB9 9772
1 Active
Digital Output 4 Latch Enable Value Output 4 Latch Enable / Disable
Dec 3002 19386 38772
RW
0 Disable
Hex 0BBA 4BBA 9774
1 Enable
Digital Output 4 Clear Latch Value Output 4 Latch Clear
Dec 3004 19388 38776
RW
0 Do Nothing
Hex 0BBC 4BBC 9778
1 Clear Latch
Digital Output 4 Latch State Value Output 4 Latch State
Dec 3003 19387 38774
RO
0 Unlatched
Hex 0BBB 4BBB 9776
1 Latched
Output 4 OR Alarm Selection Bit If Bit = 1, Alarm n Is Included in OR Selection
Dec 10127 26511 53022
RW
2 Alarm 1
Hex 278F 678F CF1E
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 4 OR Event Selection Bit If Bit = 1, Event n Is Included in OR Selection
Dec 10128 26512 53024
RW
2 Event 1
Hex 2790 6790 CF20
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
Output 4 AND Alarm Selection Bit If Bit = 1, Alarm n Is Included in AND Selection
Dec 10129 26513 53026
RW
2 Alarm 1
Hex 2791 6791 CF22
3 Alarm 2
4 Alarm 3
5 Alarm 4
6 Alarm 5
7 Alarm 6
8 Alarm 7
Output 4 AND Event Selection Bit If Bit = 1, Event n Is Included in AND Selection
Dec 10130 26514 53028
RW
2 Event 1
Hex 2792 6792 CF24
3 Event 2
4 Event 3
5 Event 4
6 Event 5
7 Profile Running
8 Profile End
