Western Digital Hard Disk Drive OEM Specification
9.18.3.4 SCT Data Table Command (action code : 0005h)
Inputs: (Key Sector)
Word
Name
Value
Description
0
Action Code
0005h
Read a data table
1
Function Code
0001h
Read Table
2
Table ID
Word
See Table 70 for a list of data tables
255:2
reserved
0000h
Table 68 SCT Data Table Command (Inputs)
Outputs: (TF Data)
Command Block Input Registers (Success)
Error
00h
Sector Count
reserved
Sector Number
reserved
Cylinder Low
Number of sectors to transfer (LSB) = 01h
Cylinder High
Number of sectors to transfer (MSB) = 00h
Device/Head
reserved
Status
50h
Table 69 SCT Data Table Command (Outputs)
Table ID
Description
0000h
Invalid
0001h
Reserved
0002h
HDA Temperature History Table (in absolute degree C). See Table 72
0003h-CFFFh
Reserved
D000h-FFFFh
Vendor Specific
Table 70 Table ID
