11.23.4 Extended Self-test log sector
Table 159 defines the format of each of the sectors that comprise the Extended SMART self-test log.
The Extended SMART self-test log sector shall support 48-bit and 28-bit addressing. All 28-bit entries contained in
the SMART self-test log, defined in 11.51.6 Self-test log data structure on page 275 shall also be included in the
Extended SMART self-test log with all 48-bit entries.
Self-test log data structure revision number
Self-test descriptor index (7:0)
Self-test descriptor index (15:8)
Table 159 Extended Self-test log data structure
These descriptor entries are viewed as a circular buffer. The nineteenth self-test shall create a descriptor entry that
replaces descriptor entry 1. The next self-test after that shall create a descriptor entry that replaces descriptor entry 2,
etc. All unused self-test descriptors shall be filled with zeros.
11.23.4.1 Self-test log data structure revision number
The value of this revision number shall be 01h.
11.23.4.2 Self-test descriptor index
This indicates the most recent self-test descriptor. If there have been no self-tests, this is set to zero. Valid values for
the Self-test descriptor index are 0 to 18.
11.23.4.3 Extended Self-test log descriptor entry
The content of the self-test descriptor entry is shown below.
Self-test execution status
Power-on life timestamp in hours
Self-test failure check point
Table 160 Extended Self-test log descriptor entry
