Western Digital Ultrastar DC HC310 - Table 106 Download Microcode DMA Command (93 H)

132
Western Digital Hard Disk Drive OEM Specification
11.5 Download Microcode DMA (93h)
Command Block Output Registers
Command Block Input Registers
Register
7
6
5
4
3
2
1
0
Register
7
6
5
4
3
2
1
0
Data
-
-
-
-
-
-
-
-
Data
-
-
-
-
-
-
-
-
Feature
SUBCOMMAND(00-07)
Error
…See Below …
Sector Count
SECTOR_COUNT(00-07)
Sector Count
-
-
-
-
-
-
-
-
Sector Number
SECTOR_COUNT(08-15)
Sector Number
-
-
-
-
-
-
-
-
Cylinder Low
BUFFER_OFFSET(00-07)
Cylinder Low
-
-
-
-
-
-
-
-
Cylinder High
BUFFER_OFFSET(08-15)
Cylinder High
-
-
-
-
-
-
-
-
Device/Head
-
-
-
D
-
-
-
-
Device/Head
-
-
-
-
-
-
-
-
Command
1
0
0
1
0
0
1
1
Status
…See Below …
Error Register
Status Register
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
CRC
UNC
0
IDN
0
ABT
T0N
AMN
BSY
RDY
DF
DSC
DRQ
COR
IDX
ERR
0
V
0
0
0
V
0
0
0
1
0
1
0
0
-
V
Table 106 Download Microcode DMA Command (93h)
Output Parameters To The Device
Feature
Subcommand code.
03h : Download and save microcode with offsets.
07h : Download and save microcode.
0Eh : Download with offsets and save microcode.
0Fh : Activate download microcode.
Other values are reserved.
Sector Count
Lower byte of 16-bit sector count value to transfer from the host.
Sector Number
Higher byte of 16-bit sector count value to transfer from the host.
Cylinder
Buffer offset (only used for Feature = 03h)
This command enables the host to alter the device’s microcode. The data transferred using the DOWNLOAD
MICROCODE DMA commands is vendor specific.
The Download and save microcode with offsets subcommand(03h) transfers the updated microcode data in one or
more DOWNLOAD MICROCODE commands. This subcommand downloads data containing a segment of the
updated microcode data. On normal command completion, the COUNT field may contain additional indicators.
If the final segment has been downloaded, the device validates the downloaded updated microcode. If the
validation is successful, the downloaded updated microcode is saved to non-volatile storage and is activated.
After transferring a segment where the value of the BUFFER OFFSET field is cleared to zero, if the device begins to
process a command that is not a DOWNLOAD MICROCODE command, then the device:
1) may discard any updated microcode data that has not been saved; and
2) shall continue to process the new command.
The Download and save microcode subcommand(07h) transfers the updated microcode data in one DOWNLOAD
MICROCODE command.
After the updated microcode data has been downloaded:
1) the device shall save the updated microcode data;
