Western Digital Ultrastar DC HC310 - Table 173 Supported Capabilities Log Page - Continued

Western Digital Ultrastar DC HC310
322 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
196
Western Digital Hard Disk Drive OEM Specification
Offset
Type
Content
8..15
QWord
Supported Capabilities
11
GPL SUPPORTED bit
10
STREAMING SUPPORTED bit
9
Reserved
8
SMART SELF-TEST SUPPORTED bit
7
SMART ERROR LOGGING SUPPORTED bit
6
EPC SUPPORTED bit
5
SENSE DATA SUPPORTED bit
4
FREE-FALL SUPPORTED bit
3
DM MODE 3 SUPPORTED bit
2
GPL DMA SUPPORTED bit
1
WRITE UNCORRECTABLE SUPPORTED bit
0
WRV SUPPORTED bit
16..23
QWord
DOWNLOAD MICROCODE Capabilities
Bit
Meaning
63
Contents of the QWord are valid
62:35
Reserved
34
DM OFFSETS DEFERRED SUPPORTED bit
33
DM IMMEDIATE SUPPORTED bit
32
DM OFFSETS IMMEDIATE SUPPORTED bit
31:16
DM MAXIMUM TRANSFER SIZE field
15:0
DM MINIMUM TRANSFER SIZE field
24..31
QWord
Nominal Media Rotation Rate
Bit
Meaning
63
Set to one
62:16
Reserved
15:0
NOMINAL MEDIA ROTATION RATE field
32..39
QWord
Nominal Form Factor [was word 168]
Bit
Meaning
63
Contents of the QWord are valid
62:4
Reserved
3:0
Nominal Form Factor
40..47
QWord
Write-Read-Verify Sector Count Mode 3
Bit
Meaning
63
Contents of the QWord are valid
62:32
Reserved
31:0
WRV MODE 3 COUNT field
48..55
QWord
Write-Read-Verify Sector Count Mode 2
Bit
Meaning
63
Contents of the QWord are valid
62:32
Reserved
31:0
WRV MODE 2 COUNT field
56..71
DQWord
World wide name [was word 108]
Bit
Meaning
127
Set to one
126:64
Reserved
63:0
World wide name
