Western Digital Ultrastar DC HC310 - Table 174 Supported Capabilities Log Page

To Next Page

To Previous Page

197

Western Digital Hard Disk Drive OEM Specification

Offset

Type

Content

72..79

QWord

DATA SET MANAGEMENT

Bit

Meaning

Set to one

62:1

Reserved

TRIM SUPPORTED bit

80..511

Reserved

Table 174 Supported Capabilities log page - Continued -
