Windhager FireWIN - Menu Guide

23
2. Operation
5s
RESET
Fig. 49
Boiler temperature
(Operating phases)
Info Menu
42
°C
5s
RESET
Fig. 50
Operator level
Service level
Information level
MES Module
1
Choose Back
5s
RESET
Fig. 51
Operator level
Service level
Information level
MES Module
1
Choose Back
5s
RESET
Fig. 52
Operator level
Service level
Information level
MES Module
1
Choose Back
2.8 Menu guide
Pressing the Menu button changes the menu display to
the Operator level, Service level, Information level or MES
Module1 – Fig. 49.
Use the arrow buttons to select the Operator level, Service
level or Information level (Fig. 50) and confirm with the
Choose button – Fig. 51.
The menu item or sub-menu item is exited by pressing the
Back button (Fig. 52) or after a delay of 45 seconds.
Information!
Only trained service personnel may perform
system modifications on the Service level.
1 only displayed when an MESplus control is present and this has been adjusted by a trained service technician in the basic settings.
