Windhager FireWIN - Operator Level

25
2. Operation
Note!
The menu items „Feed operating mode“, „Time
profile feed“ and „Probe switching “ are only
shown if a feed or probe switching function is
provided and activated in the service level.
The menu item or sub-menu item is exited by pressing the
Back button (Fig. 56) or after a delay of 45 seconds.
1 only displayed when an MESplus control is present and this has been adjusted by
a trained service technician in the basic settings.
5s
RESET
Fig. 53
Boiler temperature
(Operating phases)
Info Menu
42
°C
2.8.1 Operator level
Pressing the Menu button shows the „Operator level“,
„Service level“, „Information level“ and „MES Module
1
“ in
the display – Fig. 53.
5s
RESET
Fig. 54
Operator level
Service level
Information level
MES Module
1
Choose Back
Use the arrow buttons to select „Operator level“ and con-
firm with the Choose button – Fig. 54.
5s
RESET
Fig. 55
Boiler cleaning
Time
Feed operating mode
Time profile feed
Probe switching
Time profile ash compression
Choose Back
On the operator level, use the arrow buttons to select the
required sub-menu (Fig. 55) and confirm with the Choose
button.
Adjusting the:
Boiler cleaning: 2.8.1.1
Time: see section 2.8.1.2.
Feed operating mode: see section 2.8.1.3.
Time profile feed: see section 2.8.1.4.
Probe switching: see section 2.8.1.5.
Time profile ash compression: see section 2.8.1.6
5s
RESET
Fig. 56
Boiler cleaning
Time
Feed operating mode
Time profile feed
Probe switching
Time profile ash compression
Choose Back
