User can define the barcode scanner trigger mode from Trigger mode
options drop-down menu shown as below.
Continuous
Under Continuous mode, the barcode scanner processes auto-scan
continuously. The scanning light and pattern will be always on.
Level
Under Level mode, the barcode scanner follows trigger button behavior.
The scanning light will be on when the Fn2 button is triggered, and off when
the barcode is successfully read or the Fn2 button is released.
Pulse
Under Pulse mode, user can define the scanning time after each trigger.
The scanning light will be on when the Fn2 button is triggered, and off when
the barcode is successfully read or the defined read time ends. To set up
the scanning time, tap on the Read time options drop-down menu and
choose a preferred time frame (options from 1 second to 9 seconds).
Flashing
Under Flashing mode, the scanning light is flashing, and the barcode
scanner processes auto-scan with the same frequency.
