Tempro basic C 90 & Tempro primus C 90
Page 21
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
6.4 Operation mode
Tempro basic C 90:
Two temperature-controlled operating modes (pressure and suction temperature
control) and the empty suction function are available.
Tempro primus C 90:
Only the pressure tempering mode and the emptying by suction function are
available.
6.4.1 Pressurized stabilizing:
This is the standard operation mode in which the stabilizing medium is pumped
through hoses and tool channels.
Main switch position 1
6.4.2 Suction temperature control:
Here the temperature control medium is sucked through hoses and tool channels
(leak stop operation )
Main switch position 2
Tempro primus C 90:
This tempering mode is NOT available for the PRIMUS C90.
6.4.3 Evacuating:
In this operation mode, the stabilizing medium is sucked.
Tempro primus C 90:
Evacuating optional
Here, the tempering medium is sucked out of the mould.
Main switch position 2
