Wittmann Tempro basic C 90 - 10 Technical Data; Technical Data Tempro Basic C90 and Primus C90

Tempro basic C 90 & Tempro primus C 90
Page 47
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
10 Technical Data
10.1 Technical Data Tempro basic C90 and primus C90
The following values concern the technical data of standard devices of the
Tempro basic C 90 and Tempro primus C 90 series.
Custom devices can differ in one or several points depending on the type of
design.
Tempro basic C 90 Tempro primus C 90
Heating output kW 9 9
Pumping capacity
l/min,
bar
40,
3,8
40,
3,8
Cooling water connections Zoll ¼ ¼
Tool connection – Forward Zoll ¾ ¾
Tool connection – Return Zoll ½ ½
Electrical connection V, Hz 3 x 400, 50
Filling quantities l 9 9
Mold purge quantities l 3 ------
Dimensions
Width x
Height x
Depth
mm
235
660
590
Weight unfilled kg 31 31
