Tempro basic C 90 & Tempro primus C 90
Page 39
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
9 Repair instructions
9.1 Prior to opening the unit
§ Cool stabilizer down to safety temperature of approx. 40°C !
§ Turn OFF by main switch
§ Lock cooling water inlet
§ Disconnect stabilizer from mains voltage and secure against restart of operation
9.2 Remove side panels
The lateral parts may be removed by using simple tools (such as a large
screwdriver).
The lateral plastic shells are fixed by means of 5 snap-on attachments each
(B = point of attachment))
9.2.1 Demount of lateral parts
§ Switch OFF the device
§ Unlock the spring lock by turning the attachments “B”
§ Click away lateral part
9.2.2 Re-assembling of lateral parts
§ Align side panel on the attachment points B (important: slot must be positioned
vertically!) and lock with firm pressure.
