Wittmann Tempro basic C 90 - Service-Menu (Code 111) Display of Actual Pressure; Interface - Menu

Tempro basic C 90 & Tempro primus C 90
Page 34
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
7.16.2 Service-Menu (Code 111) display of actual pressure
Taste Display Funktion
5xMODE 123
11xDOWN 111 Code 111
1xMODE Ser Service-Menu
1xMODE A.Pr Current pressure (active pressure)
1xMODE
xx.x (xx
*
)
pressure at 1/10 bar (at 1 PSI
*
)
1xMODE P.to total pressure (total pressure)
1xMODE
xx.x (xx
*
)
pressure at 1/10 bar (at 1 PSI
*
)
1xMODE P.Sy System pressure (system pressure)
1xMODE
xx.x (xx
*
)
pressure at 1/10 bar (at 1 PSI
*
)
1xMODE P.Pu Pump- (flow-) – pressure (pump pressure) .
difference from “P.to“ and “P.Sy“
1xMODE
xx.x (xx
*
) pressure at 1/10 bar (at 1 PSI
*
)
1xMODE - - - End
* If the set temperature unit is °C, the pressure is displayed in bar; with °F, it is displayed
in PSI.
7.17 Interface – menu (Code 130
Key
Display
Fun
c
tion
5xMODE 123
7xUP 130 Code 130
1xMODE SSt COM-Menu (serial interface)
1xMODE Pro Protocol
1xMODE
Key
Display
Fun
c
tion
UP /
Down
oFF no protocol activated
P2 P2-protocol (the only supported protocol from
this device)
1xMODE Hd Hardware
1xMODE
Key
Display
Fun
c
tion
UP /
Down
oFF no interface selected
232 RS232
85.2 RS 485.2
85.4 RS 485.4
CL 20 mA – interface (current loop)
1XMODE HSt manufacturer
1xMODE
Key
Display
Fun
c
tion
UP /
Down
Arb Arburg
BtF Battenfeld
biL Billion
boy Dr.Boy
dE Demag
Eng Engel
Hus Husky
AFF Kraus Maffei
net Netstal
tYo Toyo
1xMODE bd Baudrate
