Tempro basic C 90 & Tempro primus C 90
Page 50
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
11 Options
11.1 External sensor PT100
(only for Tempro basic C 90):
When the tool temperature is monitored by an external sensor, the sensor is
connected to the 4-pole socket (PT100) in the operating panel.
Only when the stabilizer has been switched on will the entry for the tool sensor be
queried. When a valid value is recognized, control for the external sensor is
activated. When the sensor is disconnected from the socket, „Broken sensor“ will
be recognized and an alarm will be reported.
The choice which sensor will be controlled is always made only when the unit is
switched on with the main switch. The safety device „Temperature monitoring“
always remains active.
Operating panel with option PT100 installed:
1 Plug for alarm contact
2 External sensor PT100
3 Key Q2 (evacuating)
