Wizard CMC Z1 User Manual

Head Installation
Install the Head onto the Gantry
1. Remove the two 5/32” screws from the head and set aside. 1. Remove the two 5/32” screws from the head and set aside.
2. Move the gantry to the right edge of the CMC. 2. Move the gantry to the right edge of the CMC.
3. If present, remove the Head Stop Plate at the bottom of the 3. If present, remove the Head Stop Plate at the bottom of the
gantry under the belt tensioner. Two screws hold it in place. gantry under the belt tensioner. Two screws hold it in place.
Set plate and screws aside.Set plate and screws aside.
4. Point the head so that the foot block faces toward the CMC and the wheels are 4. Point the head so that the foot block faces toward the CMC and the wheels are
close to the bottom of the gantry.close to the bottom of the gantry.
5. Line up the wheels on the head to the center channels of the gantry arm and ease 5. Line up the wheels on the head to the center channels of the gantry arm and ease
the head onto the gantry.the head onto the gantry.
6. Roll the head up the gantry until it lines up to the head grabber arm on the 6. Roll the head up the gantry until it lines up to the head grabber arm on the
right side of the gantry.right side of the gantry.
7. Holding the head in position so that the head lines up neatly to the head grabber 7. Holding the head in position so that the head lines up neatly to the head grabber
arm, replace the two 5/32” screws, making sure they go into the head grabber arm and arm, replace the two 5/32” screws, making sure they go into the head grabber arm and
into the head and tighten rmly. into the head and tighten rmly.
8. If removed, replace the Head Stop Plate to the bottom of the gantry under the belt 8. If removed, replace the Head Stop Plate to the bottom of the gantry under the belt
tensioner after the head is slid onto the gantry. Note that the notched side is placed tensioner after the head is slid onto the gantry. Note that the notched side is placed
toward the gantry. toward the gantry.
10
20-36070-1 GettingStartedManualZ1FrameShop
04/07/21
Wizard™ CMC Model Z1 Hardware and Software Getting Started Guide
