Wizard CMC Z1 User Manual

Layers
1. Select the number of layers desired for this project. 1. Select the number of layers desired for this project.
Leave it at the default of 2 layers. Leave it at the default of 2 layers.
Cartridge Selection
1. Click on the cartridge icon and select the desired 1. Click on the cartridge icon and select the desired
cartridge for this layer. For this project, leave it at the cartridge for this layer. For this project, leave it at the
default cartridge, which is the 45° cartridge.default cartridge, which is the 45° cartridge.
NOTE: NOTE: Cartridges not currently available will be Cartridges not currently available will be
greyed out. greyed out.
Go to Cut Preview to Cut the First Mat
1. Click 1. Click CutCut on on
the New Openings the New Openings
Screen to take the Screen to take the
design to the design to the Cut Cut
PreviewPreview. .
Blade Depth Settings
1.Select the desired 1.Select the desired LayerLayer on the Cut Preview Screen. on the Cut Preview Screen.
2. Click on the 2. Click on the Blade Blade
DepthDepth button. button.
18
20-36070-1 GettingStartedManualZ1FrameShop
04/07/21
Wizard™ CMC Model Z1 Hardware and Software Getting Started Guide
