9. Connect the air to the head by twisting the two air ttings 9. Connect the air to the head by twisting the two air ttings
together, together, matchingmatching the colors. the colors.
10. Connect the head power plug (square connection) to the 10. Connect the head power plug (square connection) to the
head grabber arm. head grabber arm.
11. Locate the M12 cable that is attached to the grabber arm.11. Locate the M12 cable that is attached to the grabber arm.
12. Plug the other end of the M12 cable into the M12 port at 12. Plug the other end of the M12 cable into the M12 port at
the top of the head, twisting the thumbscrew to secure it.the top of the head, twisting the thumbscrew to secure it.
Hooking up the Gantry and Air Lines
Connecting the Board Cable
*Carefully align the pins of the board cable before
applying pressure to plug it in. The connector is
keyed to avoid incorrect pin alignment. Forcing
the connector will result in damage.*
1. The board cable connects the gantry on the CMC to 1. The board cable connects the gantry on the CMC to
the ECU. Connect the male end of the board cable to the ECU. Connect the male end of the board cable to
the back of the ECU by aligning the pins and turning the back of the ECU by aligning the pins and turning
the locking ring until it seats itself and locks into place. the locking ring until it seats itself and locks into place.
2. Connect the female end of the board cable to the 2. Connect the female end of the board cable to the
back of the gantry in the same manner. back of the gantry in the same manner.
3. Move the gantry to the far right of the CMC and back 3. Move the gantry to the far right of the CMC and back
to the left to make sure the board cable does not get to the left to make sure the board cable does not get
caught on anything. If the board cable is obstructed, caught on anything. If the board cable is obstructed,
this will aect the cuts.this will aect the cuts.
20-36070-1 GettingStartedManualZ1FrameShop
04/07/21
11
Wizard CMC Model Z1 Hardware and Software Getting Started Manual
Wizard™ CMC Model Z1 Hardware and Software Getting Started Guide
