Wizard CMC Z1 User Manual

CMC Parts Labeled
A: Belt anchor
B: Magnetic Stop
C: Vertical belt tensioner (not visible)
D: Head grabber arm
E Variable Pressure Optimization (VPO) gauge
F: Variable Pressure Optimization (VPO) knob
G: Vertical clamp
H: Gantry
I: Horizontal clamp
J: Lower rail, containing drive belt
K: Mat to be cut
L: Slipsheets (1-2 sheets of 4-ply)
M: Upper rail, containing drive belt
N: Horizontal tension adjustment (lower rail)
O: Horizontal tension adjustment (upper rail)
P: Control Panel
Q: ECU Brackets (attach to back of CMC)
20-36070-1 GettingStartedManualZ1FrameShop
04/07/21
7
Wizard CMC Model Z1 Hardware and Software Getting Started Manual
Wizard™ CMC Model Z1 Hardware and Software Getting Started Guide
