Wolf CT - Section 8 - Parts List and Exploded Views; IH4227 Parts List

8-4
Parts & Exploded CT Hoods and DD Ventilation
MODEL IH4227 PARTS LIST
Ref # Part # Description
1 803662 Damper Assembly
2 803665 User Interface Switch Assy
3 803670 Halogen Lamp Assy (incl bulb)
4 803816 Light Bulb
5 803672 Control Assembly
6 803677 Heat Sentry
7 803678 Grease Filter
8 803679 Outlet
Ref # Part # Description
9 803704 Decorative Flue Bottom
10 803705 Decorative Flue Top
11 803712 Lampholder Support
12 803712 Lampholder Support
13 803716 Transformer with Wires (IH4227)
14 803706 Telescopic Skeleton Bottom
15 803707 Telescopic Skeleton Top
