8-6
Parts & Exploded CT Hoods and DD Ventilation
MODEL CTEWH30I & CTEWH36I & CTEWH45I PARTS LIST
Ref # Part # Description
1 813007 Grease Filter
2 812991 Condenser
3 813015 Electrical Box Support
4 803671 Lamp Bulb
5 812998 Heat Sentry
6 812999 Motor (Clockwise)
7 812984 Blower Bracket
8 813000 Bottom Bracket
9 813012 Wires
10 813001 Glass Front Assy (30I)
813002 Glass Front Assy (36I)
813003 Glass Front Assy (45I)
11 813045 Outlet Damper-Internal
12 813008 Charcoal Filter Spacer (30I)
813009 Charcoal Filter Spacer (36I)
813011 Charcoal Filter Spacer (45I)
Ref # Part # Description
13 812990 Feeder Cable Connection Box
14 812978 Bottom Flue
15 812977 Upper Flue
16 812981 Telescopic Duct Upper Bracket
17 812988 Electrical Printed Circuit Board
18 812989 Transformer
19 813046 Main Switch
20 812994 Inside Panel (30I)
812995 Inside Panel (36I)
812997 Inside Panel (45I)
21 812982 Cover
22 812985 Blower Support Bracket
23 812992 Halogen Lamp
24 813006 Hinge
