Parts & Exploded CT Hoods and DD Ventilation
MODEL CTEIH42I PARTS LIST
Ref # Part # Description
1 813007 Grease Filter
2 812991 Condenser
3 813019 Electrical Box Support
4 803671 Lamp Bulb
5 812998 Heat Sentry
6 812999 Motor (Clockwise)
7 813014 Outlet Transition
8 813021 Blower Bracket
9 813016 Upper Bracket
10 813000 Bottom Bracket
11 813012 Wires
12 813004 Glass Front Assy
13 813010 Charcoal Filter Assy
14 812990 Feeder Cable Connection Box
Ref # Part # Description
15 812980 Bottom Flue
16 812979 Upper Flue
17 813017 Bottom Telescopic Skeleton
18 813018 Bottom Telescopic Skeleton
19 812988 Electrical Printed Circuit Board
20 812989 Transformer
21 813046 Main Switch
22 812996 Inside Panel
23 813020 Bracket Support
24 812985 Blower Support Bracket
25 812992 Halogen Lamp
26 813006 Hinge
