Parts & Exploded CT Hoods and DD Ventilation
MODEL ICBDDI & ICBDDR PARTS LIST
Ref # Part # Description
Ref # Part # Description
1 803590 Chimney Assembly 30”
803635 Chimney Assembly 36”
806430 Chimney Assembly 45”
2 804799 Trim Panel 30”
805038 Trim Panel 36”
806431 Trim Panel 45”
3 804520 Foam Seal 30”
804521 Foam Seal 36”
806432 Foam Seal 45”
4 804790 Filter Spring (4)
5 803591 Filter Assembly 30”
803592 Filter Assembly 36”
806433 Filter Assembly 45”
6 804791 Right Hand Filter Grille 30”
804793 Right Hand Filter Grille 36”
806434 Right Hand Filter Grille 45”
7 804792 Left Hand Filter Grille 30”
804794 Left Hand Filter Grille 36”
806435 Left Hand Filter Grille 45”
8 804795 Filter 30”
804796 Filter 36”
806436 Filter 45’’
9 813898 Airbox Weldment 30”
813899 Airbox Weldment 36”
813900 Airbox Weldment 45”
10 804797 Airbox Front 30”
805039 Airbox Front 36”
806438 Airbox Front 45”’
11 803614 Slide Strips
12 803613 Spacers (Set of 4)
13 814247 Lower PC Board 240V 50/60hz
14 803596 Crank Assembly
15 803607 Right Hand End Cap
16 803608 Left Hand End Cap
17 803609 Chimney Slide
18 803611 Wire Harness
19 803631 Ground Wire Assembly
20 813033 Cord Set - Intl
21 803618 Front Airbox Bottom 30”
808430 Front Airbox Bottom 36”
806439 Front Airbox Bottom 45”
22 810887 Gear Motor Bracket
23 813034 Gear Motor
24 813036 Gear Motor Cover ICBDD30I
813037 Gear Motor Cover ICBDD30R
813901 Gear Motor Cover ICBDD36I
813902 Gear Motor Cover ICBDD36R
813903 Gear Motor Cover ICBDD45I
813904 Gear Motor Cover ICBDD45R
25 803625 Airbox Clamp
26 803626 Whiz Nuts (8)
27 803722 Installation Template 30”
803723 Installation Template 36”
806442 Installation Template 45”
28 803627 Scroll Box Cover
29 808438 Scroll Box Weldment
30 803610 Blower Wire Harness
31 803612 Outlet Plate
32 810890 Adapter Plate
33 804798 Electrical Box Cover
NOT ILLUSTRATED
813039 Blower Motor w/Capacitor
803598 Blower Wheel
803600 Motor Insulator
803587 Top Cover SST 30N
803588 Top Cover SST 36N
806429 Top Cover SST 45N
813207 Interface, DNDFT-Stnls
803610 Wire Harness, Ext/Remote Blower
810082 Cable, User Interface
