C-5000 COMMUNICATION MANAGEMENT CONTROLLER
INSTALLATION MANUAL
Publication No. 150-041118 Page 5-55
Rev. A Section 5 – Configuration and Programming
Sep 2001
DOS (Data Squelch) – ENABLED
Operation – 1200-1800 Khz
Coast Time – 267.00
Sel Call Reset – Auto w/Carr
Auto Reset Time – 5
CALL LIST TABLE – Displayed by pressing F4 ! F6 ! F4 ! F4 from the Main Menu. This table is for setting
up group and individual calling in an MDC Analog system. It is not used blank.
ASTRO CONFIGURATION MENU – Displayed by pressing F4 ! F6 ! F5 from the Main Menu. This menu is
the lead in menu to configure all aspects of ASTRO operations for the radio. Options and sub-menus are as
depicted.
ASTRO RADIO WIDE – Displayed by pressing F4 ! F6 ! F5 ! F2 from the Main Menu. All of the settings
on this page should remain as shown unless directed otherwise:
Max CAI Data TX Attempts – 4 NUM DATA GROUP ID
Max CAI Packet Size – 512 1 10000000
CAI Data Response Timer – 3300 2 10000000
CAI Data Min Response Timer – 700 3 10000000
Data Frame Sync Seek Period – 750 4 10000000
Data TX Short Random Range – 50 5 10000000
Data TX Long Random Range – 2000 6 10000000
Data TX Resp Random Range – 1000 7 10000000
Data TX Limited Patience – Infinite 8 10000000
ASTRO SYSTEMS - Displayed by pressing F4 ! F6 ! F5 ! F3 from the Main Menu. This screen configures
the particulars of ASTRO Digital operations. All of the settings should remain as depicted EXCEPT the Individual
ID. This is the ASTRO ID assigned to the radio by serial number when it is first brought on line in the radio
network. It must be unique to the radio.
Astro System – 1
Individual ID – (As assigned per serial number) Emergency – Enabled
Emergency Type – Alarm Only
Acknowledge Alert Tone – Enabled
Revert Table
Preamble Length – 80 NUM ZONE CHANNEL
Status – DISABLED 1 1 1
211
Message – ENABLED 3 1 1
ASTRO SYSTEM OPTIONS - Displayed by pressing F4 ! F6 ! F5 ! F3 ! F9 from the Main Menu. This
screen allows entry of additional options and configurations for the ASTRO Mode of operation. All of these settings
should remain as shown below:
Astro System – 1
Talkgroup Hangtime – 0.0000 Emergency
Priority TX Inhibit – DISABLED
Limited Patience – 53 Polite Retries – 5
Impolite Retries – 15
To Next Page
