C-5000 COMMUNICATION MANAGEMENT CONTROLLER
INSTALLATION MANUAL
Publication No. 150-041118 Page 3-5
Rev A Section 3 – Mechanical Installation
Sep 2001
Note: For full 29.7-900 MHz frequency coverage, the user must also install the AT-400
antenna for 400-960 frequencies.
See the AT-50 and AT-51 envelope drawings, Figures 3-10 and 3-11, for dimensions.
Mount antenna with No. 10 screws.
G. FC-50
Note: The FC-50 Logic Converter is required for the AT-50 and AT-51 antennas.
See the FC-50 envelope drawing, Figure 3-14, for dimensions.
H. AT-400
See the AT-400 envelope drawing, Figure 3-13, for dimensions.
Mount antenna with No. 8 screws.
I. AT-140
Note: For full 29.7-400 MHz frequency coverage, the user must also install the AT-140
antenna for 400-960 frequencies.
See the AT-140 envelope drawing, Figure 3-12, for dimensions.
Mount antenna with No. 10 screws.
